Inside

6470X3433X2650mm (L X W X H)

Panels

Pre painted steel sheet, double skinned with insulations EPS , thickness: 60mm,

Base

300mm base, five rows of gratings, two outside ramps

Ceiling

Hanging type or supported by steel posts

Extraction

One double-intaking centrifugal fan, belt drive, angle steel frame, one 7.5KW motor, capacity:20000m3/h

By-Pass

Electric damper from spraying to baking cycle

Heating

No heating (Optional: Stainless heating exchanger, 60��C - 80��C working temperature. Riello RG5S two-stage oil burner)

Curtain

PVC curtains, steel rails

Lighting

Upper inclined lights, 8 units, 4x32W each

Control

Omron temperature controller, lights switches, spraying switch, Siemens contactors etc.
