Main Feature
1.Ultrathin structure, surface mount, the initial landing height is 105mm, occupied small space.
2.The Italy original imported hydraulic pump valve and electrical components.
3.Double cylinder drive, safe and stable synchronization.
4.Meet the needs of different vehicles repair and detection.
5.One button to adjust balance and upper return oil, prevent oil cylinder rust.
Technical Parameters
|
Lifting capacity |
3000kg |
|
Max lifting height |
1850mm |
|
Min Lifting height |
105mm |
|
Platform length |
1450mm |
|
Platform width |
635mm |
|
Lifting time |
70s |
|
Oil pressure rating |
24Mpa |
|
Voltage |
220v/380v |
|
Air pressure |
0.6-0.8Mpa |
|
Weight |
850kg |
